Control of electrical machines (asynchronous / synchronous machine)

Control of electrical machines (webinar/training)
Dates
  • Starting 3rd quarter 2022, Online Live-Seminar / Webinar
  • Number of participants limited / small class
Seminar goals

In this one-day seminar, the basic techniques for controlling rotating field machines are presented and explained (asynchronous machine and permanently excited synchronous machine). Starting with the basics of energy conversion and rotary field electrical machines, participants will learn how to model the machines and the possibilities for controlling speed and torque.

In analogy to the control of a shunt-wound DC machine, control models of synchronous and asynchronous machines are created, which allow a „decoupled“ control of field and torque. Here, the field-oriented control, which has established itself as a standard control method, is dealt with in detail.

Target group

The seminar control of electrical machines (rotating field machine) is intended for engineers, technicians, specialists, scientific staff and managers.

Content

– Fundamentals of power conversion
– Modeling of a DC shunt motor
– Structure of cascaded control: position, speed, torque
– Theory of rotating field machine
– Clarke and Park transformation
– Modeling of rotating field machines
– Field-oriented control of a permanent magnet synchronous machine
– Field-oriented control of an asynchronous machine
– Voltage control range and field weakening range
– Space vector modulation
– Conclusion and discussion

Schedule (central europe time)

09:00 – 09:15 Welcome and introduction
09:15 – 10:00 Energy conversion and modeling of a DC shunt machine
10:00 – 10:30 Control structure of a cascaded control system
10:30 – 10:45 Coffee break
10:45 – 12:00 Rotary field machines and coordinate transformation (Clarke/Park transformation)
12:00 – 13:00 Lunch break
13:00 – 14:00 Modeling of rotating field machines
14:00 – 14:45 Field oriented control of a permanent magnet synchronous machine
14:45 – 15:00 Coffee break
15:00 – 15:45 Field oriented control of an asynchronous machine
15:45 – 16:00 Voltage control range, field weakening range and space vector modulation
16:30 – 16:45 Discussion and conclusion

Attendance Fee

599,- € (plus VAT if required by law)

Registration

Starting 3rd quarter 2022

Information and cancellation

The participation fee includes the seminar documents (PDF)

Cancellation is possible free of charge until 14 days before the start of the event.

You can name a substitute participant from your company/organization free of charge up to 1 day before the start of the event.

The number of participants is limited.

Seminar / Training:
Control of electrical machines (asynchronous / synchronous machine)
